MAN Diesel & Turbo delivers 10,000th TCR turbo

Written by Nick Blenkey
image description

TCR deliveries (cumulative)

SEPTEMBER 6, 2016 — MAN Diesel & Turbo, Augsburg, Germany, reports that it recently delivered the 10,000th turbocharger from its TCR radial-type turbocharger series.

The MAN TCR14 unit was produced for a 5L23/30H GenSet for Oldendorff Carriers GmbH & Co., one of the world’s largest dry-bulk shipping companies based in Lübeck, Germany.

The Jinling shipyard built 38,000-dwt bulker is the second in a series of four vessels, all propelled with MAN two-stroke and auxiliary engines.

“The information garnered from over 10,000 TCR turbochargers in the field gives us a huge insight into their overall performance, ” said Dirk Balthasar, Vice President and Head of Turbocharger Sales & Promotion, MAN Diesel & Turbo. “The TCR series was introduced in 2004, meaning that many of these turbochargers have run for over 10 years and have had a second major overhaul. We calculate our accumulated TCR service experience now as more than 200 million operating hours. We use this knowledge to constantly improve the TCR series.”

Balthasar concluded: “This strategy can be seen to have paid dividends with this impressive sales milestone and the fact that TCR turbochargers enjoy broad support across the market and supercharge both MAN and non-MAN engine designs.”

Oldendorff’s newbuilding bulker also has a Tier II MAN B&W 5S50ME-B9.3 main propulsion engine, built by Yichang Marine Diesel (YMD), and is also optimized with a highly efficient TCR22, the largest radial-type turbocharger in the world.

The TCR series

The MAN TCR Turbocharger series was introduced in 2004 to replace the NR series – in production for nearly 50 years – and to address the very special challenges of high-, medium- and low-speed engines. The MAN TCR represents a completely new design that delivers greater efficiency, the lowest possible weight, reduced size/number of components, material optimization, easier maintenance, and quicker response behavior during acceleration.

Advanced materials mean that the TCR series can offer extended overhaul intervals, easier maintenance and longer lifetimes.

MAN TCR turbochargers were designed to address the special challenges faced by HFO, MDO, biofuel and gas engines.

Seven frame sizes are available for the entire engine power range, from 350 kW to 7 MW per turbocharger.

MAN TCR turbochargers are IMO Tier III compliant and are a robust, versatile, modular platform suitable for a wide variety of high-, medium and low-speed engine applications.

Typical applications for TCR turbochargers, apart from marine GenSets, include marine propulsion engines. TCR turbochargers are also frequently used in small, two-stroke propulsion engines and have proven their excellent reliability operating on HFO and MDO.

The TCR series can be equipped with a Variable Turbine Area (VTA) as an option to increase engine efficiency, as employed in most modern, two-stage turbocharging systems.

Different options for flow-parts and turbocharger casings allow a perfect fit with a variety of different applications and engine types.
