Milestone: MAN B&W research engine completes successful ammonia test run

Written by Nick Blenkey
ammonia test run engine

Successful ammonia test run was carried out on one cylinder of test engine at MAN Energy Solutions’ Research Center Copenhagen (RCC).

With the race on to develop engines able to burn the next generation of future fuels, MAN Energy Solutions has announced the successful first running of a test engine on ammonia at its Research Center Copenhagen (RCC). The company says that the successful ammonia test run was performed on a MAN B&W two-stroke 4T50ME-X type and produced positive results with particularly promising data regarding pilot-oil amount and combustion stability.

“This marks a major milestone on our road to developing a full-scale two-stroke ammonia marine engine,” said Gunnar Stiesch, chief technical officer at MAN Energy Solutions. “It’s been a historic week for our team at the RCC where a lot of groundwork and research has now paid off and we have gained a deep understanding of ammonia’s unique characteristics as a marine fuel, as well as its effects on fuel supply and safety systems. This successful combustion represents yet another, important step towards decarbonizing the marine market and bringing big things to zero.”

With ammonia being both corrosive and toxic to humans, MAN Energy Solutions reports that safety has been of paramount importance at all stages leading to the milestone ammonia test run. Precautions taken due to the fuel’s inherent characteristics include the construction of a custom-built “cold hall.” This can contain ammonia vapor in the unlikely event of a leak with the activation of a water screen. Robust safety features from the company’s existing dual-fuel portfolio, such as double-walled piping and system ventilation, have also been built into the ammonia engine’s design.

“This is groundbreaking for both our company and the maritime industry as a whole,” said Brian Østergaard Sørensen, vice president and head of research & development, two-stroke at MAN Energy Solutions. “That said, we know we still have a lot of hard work ahead and, over the following months, will execute a testing program that will study aspects such as heat-release, ignition, safety, pilot-oil energy fraction, NOx and N2O emissions. We then plan on rebuilding the test engine from one cylinder capable of running on ammonia to a full-scale test engine running on ammonia around the end of this year or early in 2024.”

MAN Energy Solutions says that it broadly expects to hold to its delivery timeline for the first ammonia engine, with subsequent operation onboard a commercial vessel from around 2026.

“Interest in this breakthrough has been overwhelming,” said Bjarne Foldager, head of two-stroke business at MAN Energy Solutions. “However, while we provide the decarbonizing technology, the maritime industry must show the will to implement it. Now it’s up to the International Maritime Organization to establish clear regulations that ensure that maritime actors are not penalized for choosing carbon-neutral fuels. At MAN Energy Solutions, our expectations for ammonia are positive owing to its predicted lower production cost compared to other, relevant e-fuels; we foresee around 27% of fuel used onboard large merchant-marine vessels to be ammonia by 2050.”

Thomas S. Hansen, head of promotion and customer support, MAN Energy Solutions, said: “The first MAN B&W ammonia engine will be a 60-bore engine, which will be applicable to a very wide range of vessel types. The interest in this engine is very high and we have received many queries across basically all large merchant-marine vessels. MAN Energy Solutions expects a quick uptake of ammonia-fueled engines towards the end of the current decade.”

PROJECT STEPS

The ammonia engine R&D project started in 2019 with a pre-study and investigation of ammonia combustibility. The following year, a second test-engine arrived in Copenhagen, enabling a parallel-test engine setup with different fuels at RCC; HAZID workshops on the engine concepts were performed simultaneously.

In 2021, the ammonia fuel-supply system and auxiliary systems were specified with the highest possible focus on safety, while 2022 saw the installation of the same systems at the RCC with instrumentation for test engine No. 1 for one-cylinder ammonia testing initiated.

In 2023, ammonia bunkering and service-tank facilities were built with all auxiliary systems enabling a full containment of ammonia in the unlikely event of a leak. Similarly, all auxiliary systems were initially tested with water, followed by ammonia.
