Maritime fuel cell demonstrator project shows promise

Written by Marine Log Staff
image description

Young Brothers Limited recently participated in a hydrogen fuel cell demonstration project

AUGUST 18, 2017—A report recently released by U.S. Department of Energy’s (DOE’s) Fuel Cell Technologies Office in the Office of Energy Efficiency and Renewable Energy indicates that it is possible to increase energy efficiency by up to 30% at part load and reduce emissions to zero through the use of hydrogen fuel cells in maritime applications.

During the project, a first-of-its kind hydrogen fuel cell power generator for marine applications was demonstrated to verify increased energy efficiency at part loads and reduced emissions. The project goals were to demonstrate the use of the generator in the maritime environment, identify areas requiring additional research and development, analyze the business case, and address regulatory and other market barriers.

A 100 kW generator with 72 kg of hydrogen storage was designed and built by Hydrogenics, headquartered in Mississauga, Canada, with safety and regulatory reviews by the Hydrogen Safety Panel, U.S. Coast Guard, and class society American Bureau of Shipping (ABS).

The unit supplied by Hydrogenics consisted of a 20-foot ISO standard “hicube” shipping container with a proton exchange membrane fuel cell rack, power inverter, ultra-capacitors for short term transient loading, cooling system, hydrogen storage, and system controller and data acquisition equipment. The system contains 72 kg of hydrogen at 350 bar and has a rated power of 100 kW, 240 VAC 3-phase, which can be divided among 10 plugs to power up to 10 reefers at a time.

Hawaiian interisland freight and transportation company Young Brothers Limited operated the generator for 10 months powering refrigerated containers in Honolulu.

According to the report, from the period of August, 2015 to June, 2016 the generator was used by Young Brothers on 52 different days for a total of 278 hours. It averaged 29.4 kW (gross) during this period for a total energy generation output of 7,285 kWhr and achieved a 5-minute continuous peak power of 91.3 kW (gross). Its net energy efficiency ranged from 36% to 54% over the load range of 16% to 62%.

By comparison, the reports says, the net efficiency of a comparable diesel generator efficiency is from 25% to 34% in this same load range. Using no diesel fuel and producing zero emissions at the point of use, during the demonstration period the fuel cell generator displaced 865 gallons of diesel fuel, over 16 MT of CO2 emissions, and avoided nearly 150 combined kilograms of criteria pollutants (NOx, CO, HC, PM, and SOx) as compared to an existing Young Brothers 350 kW Tier 3 diesel generator.

The report, authored by Sandia National Laboratories, says the project also identified paths forward to wider adoption of the technology in the maritime sector.
